30" Whirlpool Electric Ceramic Glass Cooktop With Two Dual Radiant Elements - WCE77US0HB
30" Whirlpool Electric Ceramic Glass Cooktop With Two Dual Radiant Elements - WCE77US0HB
30" Whirlpool Electric Ceramic Glass Cooktop With Two Dual Radiant Elements - WCE77US0HS
![](/img/brandlogo/brand_logo_23.png)
Key Features
- FlexHeat™ Dual Radiant Element
- Easy-Wipe Ceramic Glass Cooktop
- Warm Zone Element
- 5 Element Cooktop
- Hot Surface Indicator Light
Product Overview
30-inch Electric Ceramic Glass Cooktop with Two Dual Radiant Elements
Cook all your family's favorites at once and clean up quick with a 5-burner cooktop designed to make the most of your mealtime routine. Two FlexHeat™ dual radiant elements give you more flexibility and the Warm Zone element keeps food warm while you're finishing the rest of the meal. Then, easily wipe messes off the ceramic glass surface.
Additional Features
FlexHeat™ Dual Radiant Element
Get two elements in one with a 6" inner ring that's great for smaller pots and pans and a 10" expandable outer ring that makes room for larger cookware.
Easy-Wipe Ceramic Glass Cooktop
Wiping up spills is simple with the easy-to-clean cooktop.
Warm Zone Element
Keep food warm while you're finishing the rest of the meal using this low-powered element.
5 Element Cooktop
Cook more of your family's favorites and enjoy added versatility with a fifth element.
Hot Surface Indicator Light
See when the cooktop's still hot to the touch, even after it's been turned off, with a light that lets you know.
Wall Oven Compatible
Install this cooktop to work with a wall oven or on its own for added flexibility.
Electrical | |
---|---|
Power Cord Included | No |
208V Compatible | Yes |
Features | |
Power Outage Compatible | No |
Cooktop Details | |
Right Rear Element-Burner Size | 6"" |
Right Front Element-Burner Type | Dual |
Right Front Element-Burner Size | 10""/6"" |
Number of Open Bays | NA |
Number of Burner | 5 |
Left Rear Element-Burner Size | 6"" |
Left Front Element-Burner Size | 10""/6"" |
Left Front Element-Burner Power | 3000W/1900W |
Hot Surface Indicator Light | Yes |
Heating Element On Indicator Light | Yes |
Downdraft Vent | No |
Cooktop Surface Color | Black |
Cooktop Element Style | Radiant |
Cooktop Configuration | All Burners |
Automatic Pan Detection | No |
Center Rear Element-Burner Size | 6"" |
Appearance | |
Digital Display | No |
Dimensions | |
Cutout Depth Max | 20-9/16 in |
Cutout Depth Min | 20-3/8 in |
Cutout Width Max | 29-9/16 in |
Cutout Width Min | 29-1/16 in |
Depth | 21-3/4 in |
Height | 5-1/4 in |
Net Weight | 41 lbs |
Maximum Height | 5-1/4 in |
Width | 30-13/16 in |
Configuration and Overview | |
Cooktop Type | Standard |
Heating Technology | Electric |
LP Convertible | No |
Installs Over Built-In Oven | Yes |
Power Boost | No |
Size | 30 in |
EndecaProps | |
ProductOutletCategories | Cooking |
CONTROLS | |
Control Location | Right |
Infinite Heat Controls | Yes |
Knob Color | Black |
Knob Type | Dishwasher-Safe Plastic |
Energy | |
Annual Energy Usage [kWh] | 258.0 |
Details | |
Surface | Glass |
