The Relay is a value-priced spa that seats six and includes a relaxing lounge seat. This versatile model offers 40 powerful jets for a different massage in each seat.
Relay Jet System
BUCKET SEAT
Shaped to comfortably cradle your body for a long relaxing soak.
BENCH SEAT
Upright to support your back plus extra room to change your position for more hydrotherapy options.
LOUNGE SEAT
Reclined and contoured so you can lay back with your legs extended.
Features
Massage
LEGENDARY HOT SPRING MASSAGE
Comfortable seats with purposefully arranged jet systems work together to target specific muscle groups. The result is a distinctive massage from your neck to your shoulders, back, wrists, calves, and feet.
PERSONALIZED CONTROL
The Comfort Control system lets you dial in your experience—from soft touch to powerful massage. Use the SmartJet system, available on the Pace model, to customize water flow to different jet groups and seats.
Water
EASY WATER CARE
Crystal clear spa water is essential to a great spa experience. Hot Spot Collection spas come ready for the FROG @ease in-line sanitizing system (available in the U.S. only).
FROG @EASE IN-LINE SANITIZING SYSTEM
Pre-filled cartridges with SmartChlor technology and minerals self-regulate to keep water crystal clear with less effort. @ease creates softer feeling water that’s virtually free of chemical odors.
Energy
MONEY-SAVING ENERGY EFFICIENCY
Hot Spot Collection spas feature an Energy Smart System to reduce energy consumption. You can have peace of mind knowing that your spa will be hot and ready when you are, while keeping energy costs low.
ENERGY SMART SYSTEM FEATURES
- FiberCor insulation fills the cabinet completely with a density four times greater than the half-pound foam used in most spas.
- Proprietary spa covers ensure a tight fit to keep heat from escaping.
ENERGY SMART SYSTEM FEATURES
- The patented No-Fault heater uses a unique heater element that maximizes heat transfer.
Quality
THE ABSOLUTE BEST HOT TUB OWNERSHIP EXPERIENCE
You can count on lasting quality and unparalleled customer care from a global network of dealers dedicated to providing you with an extraordinary ownership experience.
Design
BEAUTIFY YOUR SPACE
Designed to delight the senses, each Hot Spot Collection spa features eye-catching finishes, dramatic LED lighting, sleek metallic corners, and distinctive design details.
SOOTHING COLOR PALETTE
Subtly embossed cabinets evoke the beauty of natural materials with the durability of advanced composites to complement your indoor and outdoor space.
ON-TREND DESIGN
A large bar top, contoured seating, and integrated pillows complement the overall design for a unique look.
| KEY SPECIFICATIONS | |
|---|---|
| Total Seats | 6 |
| Lounge Seat | Yes |
| Dimensions |
7’ x 7’ x 36” 213 cm x 213 cm x 92 cm |
| Water Care System | FROG® In-Line Cartridge Ready |
| Voltage | 230 V |
| Water Capacity |
340 g 1,290 L |
| Dry Weight |
830 lb. 375 kg |
| Filled Weight* |
4,715 lb. 2,140 kg |
| MASSAGE | |
| Jet Count | 40 |
| Jet Types |
3 - XL Directional Hydromassage 2 - XL Rotary Hydromassage 3 - Directional Hydromassage 2 - Rotary Hydromassage 30 - Directional Precision® |
| Comfort Control® | Yes |
| SmartJet® System | Yes |
| Jet Pump 1 |
Wavemaster® 6200 Two-Speed 1.5 HP Continuous Duty 3.2 HP Breakdown Torque |
| Jet Pump 2 |
Wavemaster® 6000 One-Speed 1.5 HP Continuous Duty 3.2 HP Breakdown Torque |
| Jet Pump 3 | No |
| CLEAN WATER | |
| 100% No-Bypass Filtration | No |
| High-Flow Tri-X® Filters | No |
| Dual-Action Filtration | No |
| Polyester Filters with Free-Flow Core | Yes |
| Effective Filtration Area | 65 sq. ft. |
| Water Care System | FROG® In-Line Cartridge Ready |
| Circulation Pump | No |
| Floor Drain | Yes |
| ENERGY EFFICIENCY | |
| Insulation | FiberCor® |
| Proprietary Heater | No-Fault® 4,000 W / 230 V |
| Patented Pump Shroud | No |
| Custom-Fit Insulated Cover | 3.5” to 2.5” Tapered, 2-Pound Density Foam Core with Hinge Seal |
| Bottom Seal | Polyethelyne Sealed Bottom |
| Energy Standards | Meets California Energy Commission (CEC) and APSP 14 Energy Efficiency Standards for Portable Spas |
| INTUITIVE CONTROL | |
| Control System |
IQ 2020® with LCD Control 230 V / 50 amp, 60 Hz Includes G.F.C.I. Protected Subpanel |
| Diagnostic/Ready Light | No |
| Design | |
| Cabinet Colors |
Almond Havana Storm |
| Shell Colors |
Alpine White Pearl Pebble Tuscan Sun |
| Cover Colors |
Nutmeg Stone |
| Water Feature | Waterfall |
| Lighting System - Interior | Multi-Color LED Points of Light |
| Lighting System - Exterior | Multi-Color LED Lighting with Timer |
| Polymeric Substructure | No |
| OPTIONAL ACCESSORIES | |
| Smart Spa Technology | Yes |
| Cover Lifters |
CoverCradle® CoverCradle II UpRite® Lift ‘n Glide® |
| Steps | Hot Spot® Collection Step or Polymer Step |
| Bluetooth® Music System | Yes |
| Subwoofer | Yes |
| CoolZone™ Cooling System | No |
| FreshWater® III Ozone System | Yes |
| Warranty | |
| No-Leak Shell | 5 Years |
| Shell Surface | 2 Years |
| Cabinet | 2 Years |
| No-Leak Plumbing | 2 Years |
| No-Fault® Heater | 2 Years |
| Component Warranty | 2 Years |
| Interior Light Assembly | 2 Years |
| Wireless Remote Control Battery | No |
